GA-1000 | 4G LTE / SUB-6 5G | High Gain| Directional | MIMO 2×2 / MIMO 4×4 External Outdoor Antenna

The GA-1000 is a directional high-gain sub-6 5G antenna.

  • ● High Gain
  • ● 4G/5G Wide Bandwidth
    The antenna covers 617~6000 MHz and supports 3G/4G/4G LTE/Sub-6 5G cellular network connections.
  • ● MIMO 4 X 4 Antennas (Multi-Input Multi-Output)
    Supports MIMO 2 X 2 / MIMO 4 X 4 routers with external antenna connectors.
  • ● Directional Reception
  • ● Lightweight and Easy to Install
  • ● Flexible Angle Adjustment
Categories: ,
Overview

Overview



Description 4G LTE / SUB-6 5G | High Gain| Directional | MIMO 2×2 / MIMO 4×4 External Outdoor Antenna

The GA-1000 Sub-6 5G Antenna is designed to enhance cellular connectivity, especially when you are far from a cellular tower. This model supports 3G/4G/4G LTE/Sub-6 5G cellular network signal connection with a wide frequency band of 698-6000MHz.

With the GA-1000 Sub-6 5G antenna, you can get a stronger cellular signal compared to the internal antennas of your router, maximizing the efficiency of your router device.

If your 4G LTE or 5G router supports MIMO 2 X 2 or 4 X 4 external antennas and you want the absolute best data rates, then using MIMO 2 X 2 or MIMO 4 X 4 external antennas is usually one of the best options.

Best 4G/ 4G LTE /5G ANTENNA to boost 5G Signal at home

Best 4G/ 4G LTE /5G ANTENNA to boost 5G Signal at home

Here are the situations where an omnidirectional Mino 4 X 4 4G/4G LTE/5G external antenna can be useful:

Best 4G/ 4G LTE /5G ANTENNA to boost 5G Signal at home

1. Rural Connectivity: Enhances internet access in rural areas where broadband access is typically limited.

Best 4G/ 4G LTE /5G ANTENNA to boost 5G Signal at home

2. Rural Home Broadband:
When using a 5G mobile hotspot in areas with weak indoor signal strength, an external antenna can significantly enhance signal reception by capturing stronger signals from nearby 5G base stations. Additionally, the external antenna amplifies and stabilizes the signal, which is crucial in areas where 5G signals struggle to penetrate walls or reach indoor spaces.

Best 4G/ 4G LTE /5G ANTENNA to boost 5G Signal at home

3. Industrial Connectivity: Ideal for businesses utilizing IoT devices, surveillance systems, and other critical applications requiring consistent 5G connections.

Best 4G/ 4G LTE /5G ANTENNA to boost 5G Signal at home

4. Home Internet Stability: Ensures a stable and high-speed internet connection for home setups, particularly beneficial in regions with fluctuating 5G signals.



Overall, the GA-1000 Sub-6 5G Antenna is an invaluable asset for anyone looking to optimize their 5G connectivity, whether it’s for home use, industrial needs, or providing service in geographically challenging environments.

Best 4G/ 4G LTE /5G ANTENNA

Best 4G/ 4G LTE /5G ANTENNA

Features

Features

The GA-1000 is a directional high-gain sub-6 5G antenna.

●High Gain
●4G/5G Wide Bandwidth
The antenna covers 617~6000 MHz and supports 3G/4G/4G LTE/Sub-6 5G cellular network connections.
●MIMO 4 X 4 Antennas (Multi-Input Multi-Output)
Supports MIMO 2 X 2 / MIMO 4 X 4 routers with external antenna connectors.
●Directional Reception
●Lightweight and Easy to Install
●Flexible Angle Adjustment

Specification

Specification

• Covered Services: 3G / 4G / 4G LTE / Sub-6 5G
• Frequency Range: 617~6000 MHz
• Peak Gain: 9~11 dBi (excluding cable loss)
• Directionality: Directional
• Rotate Angle: Vertical / Horizontal ± 45 degrees
• Cable (attached to main unit): RG58U 1 ft (30 cm), N-type Female
• Cable Included (optional):
>>>RG58U 30 ft, N-Male to SMA-Male for 4G/5G booster
>>>Equivalent to LMR240, 30 ft, N-Male to SMA-Male
>>>Equivalent to LMR195, 15 ft, N-Male to SMA-Male

• Waterproof Level: IPX5
• Body Dimension: 284 x 203 x 66 mm
